| Model |
GT1106RB |
GT1106RL |
GT1110RB |
GT1110RL |
| Rate Power |
6kVA/6kW |
6kVA/6kW |
10kVA/10kW |
10kVA/10kW |
| Cold start |
Default output 50/60Hz |
| Input voltage range |
110～288VAC；100% load@>176VAC；90% load@>154VAC；75% load@>132VAC；50% load@>110VAC |
| Input power factor |
≥0.99 |
| Frequency range |
40-70Hz |
| Output power factor |
1.0 |
| Output |
Rate voltage |
220/230/240VAC,200/208VAC(PF=0.9) |
| Load response |
≤5% (0% - 100% -0%) |
| Recovery time |
≤40ms (0% - 100% -0%) |
| THDu |
≤1%, linear load ;≤ 5% , non-linear load according to IEC62040-3 |
| Transfer time-Main to Battery |
0ms |
| Transfer time-INV to BYP |
0ms |
| Crest factor |
3:1 |
| Battery type |
12VDC/7Ah |
External battery |
12VDC/9Ah |
External battery |
| Battery Number |
16PCS |
16-24 PCS settable |
16PCS |
16-24 PCS settable |
| Battery voltage |
192VDC (default),settable |
| Max charging |
1A |
8A |
1A |
8A |
| Efficiency –normal mode |
Max 95.5% |
| Noise (1 meter) |
<58dB |
| Overload |
Normal |
105%~110%: 10mins,111%~125%: 1 min,126%~150%: 30 seconds |
| ECO mode |
<125%: long time,126%~130%:5mins,131%~150%:1min,>150% :200ms |
| Communication |
RS232, EPO, RS485 |
| Option |
AS400, USB, SNMP card, 12A charger, Parallel kit, Air filter |
| Dimension ,W*D*H(mm) |
440*660*172 |
440*580*86 |
440*660*172 |
440*580*86 |
| Weight (kg) |
63 |
16 |
63.0 |
18 |
