GT-Smart Series Micro Data Center Service Cabinet Solution

🔺GT-Smart Series Micro Data Center Solution, also know as the mini & micro integrated data center, integrates UPS, air conditioner.
🔺Power distribution module, monitoring system, temperature and humidity detection, light and access control in a standard 19-inch server cabinet.
🔺All equipment is pre-installed and precommissioned in the factory. The on-site installation is easy and convenient, which can realize rapid deployment.
🔺Occupy less area, and comes with remote web interface monitoring function, which can realize remote operation and maintenance of a site.

Safe and reliable.

Easy installation and rapid deployment.

Efficiency and energy saving.

Inquire Now
  • Micro Data Center Service Cabinet Solution Gottogpower2
  • Micro Data Center Service Cabinet Solution Gottogpower2
  • Micro Data Center Service Cabinet Solution Gottogpower2

Share:

  • Introduction

  • Parameters

GT-Smart Series Micro Data Center Solution, also know as the mini & micro integrated data center, integrates UPS, air conditioner,power distribution module, monitoring system, temperature and humidity detection, light and access control in a standard 19-inch server cabinet. All equipment is pre-installed and precommissioned in the factory. The on-site installation is easy and convenient, which can realize rapid deployment, occupy less area, and comes with remote web interface monitoring function, which
can realize remote operation and maintenance of a site.

Easy installation and rapid deployment:
🔺Modular design of power distribution, easy installation and maintenance.
🔺Rack-mounted air conditioner indoor unit, pipe thread connection, easy maintenance.
🔺The computer room does not need special decoration treatment, and the equipment is ready to use. 🔺Installation and commissioning cycle only need 3 hours.
🔺A single cabinet is a complete system, which can be easily and quickly expanded to 2-3 cabinets side by side.

Efficiency and energy saving:
🔺Proximal refrigeration, high-efficiency power supply, and the overall annual average PUE of single cabinet ≈ 1.30.
🔺The power distribution, UPS, monitoring, and refrigeration cabinets are integrated to save space.
🔺Engineering free design, free decoration and wiring, remote operation and maintenance are not on duty, saving TCO.

Intelligent management:
🔺The monitoring system is extensible and compatible with third-party monitoring systems; friendly human-computer interface.
🔺Support local and remote WEB interface access, SMS alarm function.

System IT rated power 3kVA
Mains 220Vac,50Hz/60Hz
Ambient temperature 0-45℃
Ambient humidity 10-95% (Relative humidity)
IP Class IP5X
Altitude 1000m,  dereating for >1000m
Cabinet Dimension(W*D*H) 600*1200*2000mm(Without caster)
Space occupation ≤32U
Display 10.1’’ touch screen LCD
Ambient Light Front RGB three-color ambient light
Lighting method Front and rear LED
Cable entry Top and bottom
Access control system Fingerprint + swipe card(IC&ID) + digital password three in one
Power Supply and Distribution System Distribution module Configuration Main CB: 63A/2P, rack installation, with the indicator of operation
Lightning protection Class C lightning protection (Standard for 2P, optional for 1P+N)
Height 3U
UPS Capacity 3kVA/6kVA
Power dstribution  Single phase in and single phase out
Battery Built-in battery or external battery cabinet
PDU Normal type IEC C13*2pcs, 16 ports (13*10A+3*16A)
Intelligent type Optional for 24 ports
Monitoring System Supervision system Intelligent integrated monitoring host
Single cabinet Single cabinet control module
Environment monitoring smoke detector*1
Temperature&humidity detector*1
Water leakage detector*1
Webcam(optional)
Infrared detector(optional)
Other detector SMS alarm (optional)
Emergency Ventilation Emergency measures Emergency pop-up door system
Cooling System Air conditioner Rack type (Standard for constant temperature)
Rated cooling capacity 3.7kW
Rated power consumption 1.2kW
Rated air volume 700m³/h
Drop height -5m≤△H≤10m
Mechanical Package dimensions 720*1338*2230mm
Weight 188kg (without AC, UPS, battery pack)
Cabinet color  Black (RAL9004)
