GT5000 Medium-Sized Integrated Data Center Service Solution

Gottogpower GT5000 is a complete self-contained modular data-center designed by Gottogpower experts to enable rapid and risk-free IT deployments. With capacities up to 15 racks, integrating cooling, UPS, power distribution, and emergency ventilation, the GT5000 enables standardization of complete micro datacenter configurations across multiple locations.

High reliability, engineering productization

Intelligent management

High energy efficiency

Inquire Now
  • Medium-Sized Integrated Data Center Service Solution-Gottogpower1
  • Medium-Sized Integrated Data Center Service Solution-Gottogpower1

Share:

  • Introduction

  • Parameters

Gottogpower GT5000 is a complete self-contained modular data-center designed by Gottogpower experts to enable rapid and risk-free IT deployments. With capacities up to 15 racks, integrating cooling, UPS, power distribution, and emergency ventilation,the GT5000 enables standardization of complete micro datacenter configurations across multiple locations.

Small data centers and campus data centers, Banking, Financial and Insurance, Education,
Healthcare, Manufacturing, Retail and Wholesale, Transportation.

High reliability, engineering productization, prefabricated installation, redundant design of key systems and components to enhance overall system reliability.
Intelligent management, supporting various alert methods such as SMS, phone calls, emails, and audio-visual signals, with multiple human-machine interaction methods including remote apps, local LCD, and web interface.
High energy efficiency, adopting high-efficiency intelligent modular UPS, integrated distribution design, various modes of rack/In-row precision air conditioning, closed channel deployment, empowering data centers to achieve optimal PUE.
Factory pre-installation, standardized components, modular architecture, plug-and-play, facilitating rapid deployment of data services.

Model GT5000
System Cabinets number 1-15
Power grid system Single Phase: 220Vac,50Hz, 1Ph+N+PE; Three Phase: 380Vac, 50Hz, 3Ph+N+PE
Ambient temperature 0-45°C
Ipxx IP5X
Cabinet Dimension(W*D*H)mm 600*L*2000 (W/O wheels)
Display 10 inches touch screen LCD
Lighting LED lighting+RGB
Cable entry Up and Down
Access control Fingerprint + IC card + face ID
Emergency cooling Pop-up door
PDM Input current 63-200A
SPD Class C
UPS Capacity 3-10kVA 20kVA-120kVA
Input 1P: 220Vac,50Hz,1Ph+N+PE; 3P: 380Vac, 50 Hz, 3Ph+N+PE
Work operation 1P/1P; 3P/1P; 3P/3P
Battery Packs or cabinets
PDU 13*IEC C3+3*IEC C9 or customized
Cooling Input Connect to utility
Capacity 3.5-25kW
Installation Rack or In-row
Ventilation Back to front
Compressor VF
Monitoring Integrated intelligent monitoring screen
Power monitoring(UPS, load)
Smoke sensor
Temp.and humidity sensor(option)
Water leakage sensor
Network Camera(option)
Infrared sensor(option)
SMS alarm(option)
Acoustic-optic alarm(option)
